The local planning framework
Trace's planning team prepared a justification report for a residential proposal on a sloping 1,456m² corner lot in City Beach, addressing variations to the Town of Cambridge's local planning framework including overshadowing, retaining walls and setbacks.
Justification report for variations to the local planning framework
The site is a 1,456m² corner lot with a significant slope. Our planners assessed the proposal against the Town of Cambridge's Local Planning Scheme No. 1, the Residential Design Codes Volume 1 and other relevant local policies. This covered retaining walls, lot boundary setbacks, building height, and street walls and fences.
The Town raised a concern about overshadowing. Through modelling and analysis, we demonstrated that the proposed design would overshadow less than 25% of the adjoining property's site area, which complies with local standards. We also clarified the method used to calculate overshadowing.
The proposed retaining wall within the secondary street setback was another focus. Our analysis showed that the new section of wall, which fills a gap for pedestrian access, would match the existing wall's height and fit with the overall design. The approach maintained and improved passive surveillance, keeping a visual connection between the dwelling and the street.
For building materials, we proposed castellated cladding alongside traditional materials such as brick and concrete. This varies the material palette and reduces the visual bulk of the building from the street. We recommended a condition requiring ongoing maintenance of the cladding to preserve its appearance.
The resulting proposal met the intent and objectives of the local planning framework while respecting the amenity of adjoining properties and the public realm. Strategic justifications and design amendments carried the application through to a decision.
LOCATION
City Beach, Western Australia
DATE
July 2024
DEPARTMENT
Urban & Regional Planning
